1000/2000kn Hydraulic Tensioner Computer Control UTM For Stranded Steel Wire Rope

  • 1
  • 2
  • 3

Brand Name : OEM / KINGENTER

Model Number : WAW-G1000

Certification : ISO CE SGS

Place of Origin : China (Mainland)

MOQ : 1 Set/Sets

Price : US $27,000-30,000 / Sets | 1 Set/Sets (Min. Order)

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 50 Set/Sets per Month

Delivery Time : 8-10days

Packaging Details : plywood packing

Piston stroke : 250mm

Power : Hydraulic

Stranded wire clam : 8--21.8mm

Max. test force(kN) : 1000KN

Structure : Four columns two ball screws, oil cylinder down-setting type

Load range : 1%-100%FS

Clamping mode : Hydraulic automatic

Contact Now

1000/2000kn Stranded Steel Wire Rope Hydraulic Machines Steel rope Hydraulic Tensioner Computer Control UTM Manufacturer





1. Technical Parameters
MODEL
WAW-1000G
Max. test force(kN)
1000KN
Structure
Four columns two ball screws, oil cylinder down-setting type
Load range
1%-100%FS
Load Accuracy
±1%
Max. Tensile testspace
1100mm
Max. Compression test space
1100mm
Piston stroke(mm)
250mm

Stranded wire clamping range
Φ8-21.8mm
Clamping mode
Hydraulic automatic
Size
Main body: 1090×890×2890
And control cabinet 820×660×1660
Weight
Main body :3600kg
Control cabinet :580kg
2. Application This machine is mainly used to test the tensile strength of steel strand wires . And is equipped with special tensile fixture and special jaws .
1000/2000kn Hydraulic Tensioner Computer Control UTM For Stranded Steel Wire Rope
1000/2000kn Hydraulic Tensioner Computer Control UTM For Stranded Steel Wire Rope

FAQ:



1. Are your company a trading one or a factory?
Factory + trading company (integration), 21 years focusing on test instruments field, 15 years exporting experience.

2. After an order is placed, when to delivery?
Generally about 15 working days, If we have inventory, we can arrange shipment within 3 working days.
Please be aware that our production lead times depend on specific items and item quantities.

3. What about the warranty with after - sales services?
12 months warranty after delivery. Besides,we can help you to repair your problem controller freely,even it's not from our factory. What you need to do is to send us the controller.
After the warranty, the professional after-sale service team will provide perfect technical support,and help customer solve problems encountered while using our product, handles guest problems and complaints in
a professional and timely.

4. What about the services and product' quality?
Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.
Product use training, each of our product provide video training to show you how to install & operate.
All the products meet with: ISO, ASTM, AATCC, BS, EN, DIN, JIS and other required standards.
